Key Assets

– G2277 (2 Units Available)

132 / 176 / 220 MVA

HV of 380 kV and 1425 kV BIL

LV of 13.8 x 13.8 kV and 250 kV BIL

OLTC at HV

Z = 13.0 % @ 110 MVA

60 Hz.

G2277 – Click here for additiona details

HA_G2277 – Unit Details G227

– G2044 (1 Unit Available)

130/ 180 / MVA

HV of 400 kV and 1425 kV BIL

LV of 18kV and 250 kV BIL

OLTC at HV

Z = 14.75 % @ 180 MVA

60 Hz.

G2044 – Click here for additional details

HA_G2044 – Unit Details G2044

– G2092 (1 Unit Available)

170 / 240 MVA

HV of 230 kV and 1050 kV BIL

LV of 18kV and 250 kV BIL

OLTC at HV

Z = 14.75 % @ 240 MVA

60 Hz.

G2092 – click here for additional details

HA_G2092 – Unit Details G2092

More Details To Follow
