Key Assets
Details
| Module size: | |
| Length, approx. | 1,004 mm |
| Width, approx. | 1,204 mm |
| Front Glass (Borosilcate): | |
| Length, approx. | 1,000 mm |
| Width, approx. | 1,200 mm |
| Glass panel thickness general | 1.1 – 1.8 mm |
| Considered for design of the line | 1.3 mm |
| Tolerance glass panel length and width | + / -1 mm |
| Tolerance glass panel thickness | + / – 0.1 mm |
| Waviness of the glass panel maximum | 10-3 mm / mm |
| Glass panel flatness | 0.3 mm |
| Warpage of the glass panels maximum | 3 mm |
| Back Glass: | |
| Length, approx. | 1,004 mm (2mm on each side) |
| Width, approx. | 1,204 mm (2mm on each side) |
| Glass panel thickness | 1.3 – 5.8 mm |
| Considered for design of the line | 4 mm |
| Tolerance glass panel length and width | + / -1 mm |
| Tolerance glass panel thickness | + / – 0.1 mm |
| Waviness of the glass panel maximum | 10-3 mm / mm |
| Glass panel flatness | 0.3 mm |
| Warpage of the incoming modules maximum | 3 mm |
| Module height, general | 2.9 – 8.2 mm |
| Module height considered | |
| for design of the line approx. | 6 mm |
| Lamination foil overhang on all sides | |
| (without edge sealing) | +2 up to max. + 5 mm |
| Lamination foil thickness | has to be adjusted to the module built-up |
